7.3
mikroBUS
The mikroBUS
pitch. The mikroBUS
Table 16 shows the definition of the pins.
Pin name
PA0
PB10
PA15
PA5
PA6
PA7
-
-
UM3292 - Rev 1
™
compatible connectors (CN12 and CN13)
™
compatible connectors CN12 and CN13 are a pair of 1×8-pin female connectors with a 2.54 mm
™
pinout assignment is available at the mikroe.com website.
Table 16. Description of the mikroBUS
™
mikroBUS
Pin number
function
AN
RST
CS
SCK
MISO
MOSI
+3.3 V
GND
™
connector pins
Pin number
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
UM3292
Connectors
™
mikroBUS
Pin name
function
PWM PB3
INT PB4
RX PA3
TX PA2
SCL PB8
SDA PB7
+5 V -
GND -
page 24/33
