7.2

Extension connectors (CN7 and CN10)

The extension connectors are two 2x20 2.54‑pitch male pin headers (CN7 and CN10). They can be used to
connect the STM32U083C-DK Discovery kit to an expansion or prototype/wrapping board placed on top of it. All
signals and power pins of the STM32 are available on the extension connectors. An oscilloscope, a logic
analyzer, or a voltmeter can also probe this connector.
Table 15 describes the CN7 and CN10 connector pinout.
Pin name
PD4
PC10
PB9
VDDUSB
PF3-BOOT0
PD6
PD9
(1)
PA13
(1)
PA14
PA8
PD0
PA9
PC13
(2)
PC14
(2)
PC15
(2)
PF0
(2)
PF1
VBAT
PC2
PC3
1. PA13 and PA14 are shared with SWD signals connected to STLINK-V2EC. It is not recommended to use them as I/O pins.
2. Refer to Section 6.5
3. Refer to Table 12
4. Refer to Table 13
5. The ADC input range is 0 <= VIN <= VREF.
UM3292 - Rev 1
Table 15. Pin assignment for the STM32 on the extension connectors
CN7
Pin number Pin number
1 2
3 4
5 6
7 8
9 10
11 12
13 14 VDD_MCU
15 16
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40
for details.
for details.
for details.
Pin name Pin name
PD5 PD3
PC11 PC9
E5V PB8
PD12 PB7
PD13 AVDD
PE7 AGND
PA5
NRST PA6
VDD PA7
5V PA15
GND PC7
GND PB6
PE8 PD2
PE9 PB10
PA0 PB4
PA1 PB5
PA4 PB3
PB0 PC12
PC1 PA2
PC0 PA3
CN10
Pin number Pin number
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40
UM3292
Connectors
Pin name
PA10
PC8
PC6
PC5
(5)
VREF
PD8
(3)
PA12
(3)
PA11
(4)
PB12
PB11
GND
PB2
PB1
PB15
PB14
(4)
PB13
PD1
PC4
(4)
PD11
(4)
PD10
