2. Note that the diameter of the holes in the L
brackets are slightly oversized to provide for
precise positioning (squaring) of the
with the rest of the assembly. To
Faceplate
prepare for squaring, loosen the
turning it counter-clockwise.
3. Set the miter angle at 0° by rotating the
. To set the miter angle, read the
Angle Dial
protractor marking at the edge of the
.
Dial
4. After selecting 0°, tighten the
clockwise.
Vertical
slightly by
Grip
Miter
Miter Angle
by rotating it
Grip
5. Use a precision square against the side of the
miter bar without expansion discs to square the
Vertical Faceplate
Socket-Head Bolts
included 4mm hex wrench.

ADJUST THE MITER BAR FIT

Follow the instructions below to ensure the miter bar of
your Revolution Miter Gauge is optimally fitted to the
miter slot in your machine. Perform this procedure prior
to altering any other points of fine calibration discussed
later in this manual.
If the Revolution Miter Gauge is moved between
multiple tools in your shop (e.g. a table saw and
bandsaw), be mindful that miter gauge slot
dimensions may vary slightly between tools. When
the miter bar fit is optimized for one machine, the
fit may be less than optimal when used with a
different tool. For best results, the steps described
below should be repeated before using this miter
gauge in a different machine than the tool for
which the miter bar was previously fitted.
Revolution Miter Gauge Owner's Manual
as you finish tightening the four
you inserted in step 2. Use the
|
