SET THE MITER ANGLE

Learning to use your Revolution Miter Gauge first
requires an understanding of the main controls.
To set the miter angle, DO NOT grab the fence and
rotate it in relation to the miter bar. Your SawStop
Revolution Miter Gauge is unlike any other in the
marketplace. Follow the instructions in this
chapter to learn its unique controls and proper
method for setting the miter angle.

Whole Degree Increments

Follow the steps below to set the miter angle on your
Revolution Miter Gauge for whole degree increments.
1. Loosen the slightly by rotating it counter-
Grip
clockwise.
2. Set the
Fractional Degree Selector
3. Rotate the
Miter Angle Dial
angle is indicated, then re-tighten the
example image below shows a 15° left miter
angle.
Revolution Miter Gauge Owner's Manual
to "1".
until the desired miter
. The
Grip
|
