5. Read the lower ruler here to determine the
length of cut.
6. When you reach the desired extension length,
re-tighten the silver, knurled
by rotating it clockwise until it feels
Release
locked.
To ensure measurement accuracy when utilizing
the flip stop in conjunction with the telescoping
fence extension, always begin by positioning the
as described above in step 1.
Flip Stop Assembly
Also, confirm that you have followed the
instructions for ZERO THE FENCE RULER on
page 1.
POSITION THE FLIP STOP - GROSS
ADJUSTMENTS
Your Revolution Miter Gauge is equipped with a moveable
stop that works in conjunction with the
can be re-positioned along the length of the fence to
provide for repeatable, fixed-length cuts. Just position
the stop where you want it, butt your workpiece against
the stop, then make the cut.
|
16
Revolution Miter Gauge Owner's Manual
Fence Extension
. It
Fence Assembly
1. Move the red, flip stop release lever to the 10
o'clock position as shown to open the clamp on
the underside of the
2. Slide the
Flip Stop Assembly
extrusion to the desired distance
Fence Assembly
from the blade. Read the built-in ruler on the
fence at the edge of the flip stop carrier here.
To ensure accurate readings from the ruler
attached to the
Fence Assembly
Miter Gauge, be sure read the instructions for
CALIBRATION on page 21 and ZERO THE FENCE
RULER on page 23.
.
Flip Stop Assembly
along the top of the
of your Revolution
