USING THE FENCE SYSTEM

The 22 inch
Fence Assembly
Gauge offers extended support for bigger material but
also has some added benefits. Those additional features
and how to use them are discussed below.

Setting Safe Fence Distance from Blade

To ensure maximum support of the workpiece, position
the
to run close to the blade where
Fence Assembly
friction on the workpiece is greatest during cutting
operations. Be sure there is an adequate margin for
safety.
1. With the machine powered off, place the miter
gauge into the miter slot. Move the miter gauge
down the length of the miter slot and confirm
that no part of the
of the blade.
|
14
Revolution Miter Gauge Owner's Manual
on your Revolution Miter
is in the path
Fence Assembly
2. Adjust the
Fence Assembly
needed, then tighten the
back side of the miter gauge body to secure the
fence from moving during cutting operations.
If you change the miter angle, the clearance
between the fence and blade may also change. To
minimize risk of injury and damage to your miter
gauge, re-confirm that a safe margin of clearance
is present (described above) after any miter angle
adjustment is made.
The built-in ruler on the miter gauge
is used in tandem with the adjustable flip
Assembly
stop. For measurement readings on the ruler to be
meaningful, specific setup steps related to
positioning of the
Fence Assembly
blade are required. See ZERO THE FENCE RULER
on page 23 for detailed instructions.

Reversing the Fence Orientation

The Revolution Miter Gauge fence is fully configurable to
facilitate use of the miter gauge in the miter slot to the
left or the right of a table saw blade. The dovetail-shaped
slot is identical on the front and back side of the
extrusion to enable this versatility.
Assembly
to the left or right as
on the
Thumbscrews
Fence
in relation to the
Fence
