SawStop REVOLUTION TSA-RMG Owner's Manual page 24

(toward the blade) to confirm that it is firmly
against the stop, then re-tighten the
. The edges of the upper and
Extension Release
lower extrusions that make up the
are now aligned.
Assembly
3. Loosen both silver, knurled
slightly. The
Fence Assembly
relation to the
Miter Gauge Body
4. With the machine turned off and unplugged,
raise the saw blade to full height.
5. Using a reliable ruler against the saw blade,
align the 2" mark on your reference ruler with
the 2" mark on the built-in ruler of the
. Adjust the position of the
Assembly
left or right until this alignment is
Assembly
achieved.
|
24 Revolution Miter Gauge Owner's Manual
Fence
Fence
Thumbscrews
is now adjustable in
.
Fence
Fence
It is critical that this measurement is to
the side of the blade teeth and not to flat
of the steel surface of the blade. Teeth are
typically wider than the steel of the blade
making this detail important to achieving
precision.
6. Secure the
Fence Assembly
silver, knurled
Thumbscrews
step 3.
This calibration procedure is now complete. The built-in
ruler can be relied upon for accurate cut lengths.
Read the ruler from the edge of the moveable flip stop
carrier as shown in the illustration below.
The instructions in this procedure assume the
miter gauge is currently configured for use in the
table saw miter slot to the left of the blade. If you
perform these calibration steps and later choose
to change the setup of your miter gauge for use in
the right side miter slot (see Reversing the Fence
Orientation on page 14) or shift the fence position
for any other reason, this calibration procedure
will then need to be repeated.
by tightening both
you loosened in
