If you change the miter angle, the
clearance between the fence and blade
may also change. To minimize risk of
injury and damage to your miter gauge,
re-confirm that a safe margin of
clearance is present (described
above) after any miter angle adjustment
is made.

INSTALL THE FLIP STOP ASSEMBLY

Use the following steps for initial installation of the
.
Stop Assembly
1. Move the red flip stop release lever to the 10
o'clock position as shown to open the clamp on
the underside of the
bottom of the
Flip Stop Assembly
the top rail of the
2. Continue to slide the
top of the
Fence Assembly
desired distance from the blade.
|
10 Revolution Miter Gauge Owner's Manual
. Slide the
Flip Stop Assembly
over the end of
extrusion.
Fence Assembly
along the
Flip Stop Assembly
extrusion to the
3. Move the red flip stop release to the 2 o'clock
position (as shown) to secure the
Assembly
4. The
Flip
positioned for your first cut. Reposition the
Stop Assembly
releasing the red, flip stop clamp as described
above, then securing it again at the new
location.
Be sure to visit the section on CALIBRATION on page 21
of this manual for instructions on setting up the built-in
ruler to read accurately.
Congratulations! The assembly of your Revolution Miter
Gauge is now complete.

BASIC USE

This portion of the manual discusses basic use of your
Revolution Miter Gauge such as setting the miter angle,
using the fence system, and how to use the adjustable
flip-stop system. The main controls on your Revolution
Miter Gauge are labeled in the next illustration. These
controls are referenced by name in the instructions that
follow.
in place.
is now installed and
Flip Stop Assembly
as needed for future cuts by
Flip Stop
Flip
