P-51D MUSTANG
4) Delect the lap and completely saturate
each hinge with thin C/A glue. he lap's
front surface should lightly contact the wing
during this procedure. Ideally, when the
hinges are glued in place, a 1/64" gap or less
will be maintained throughout the lengh of
the lap to the wing panel hinge line.
NOTE : he hinge is constructed of a spe-
cial material that allows the C/A to wick
or penetrate and distribute throughout
the hinge, securely bonding it to the wood
structure of the wing panel and lap.
5) Turn the wing panel over and delect the
lap in the opposite direction from the oppo-
site side. Apply thin C/A glue to each hinge,
making sure that the C/A penetrates into
both the lap and wing panel.
6) Using C/A remover/debonder and a pa-
per towel, remove any excess C/A glue that
may have accumulated on the wing or in the
lap hinge area.
7) Repeat this process with the other wing
panel, securely hinging the lap in place.
4
T-pin.
Hinge.
hin CA.
Instruction Manual.
8) Ater both lap are securely hinged, irmly
grasp the wing panel and lap to make sure
the hinges are securely glued and cannot
be pulled out. Do this by carefully apply-
ing medium pressure, trying to separate the
lap from the wing panel. Use caution not to
crush the wing structure and/ or lap.
Note : Work the lap up and down several
times to "work in" the hinges and
check for proper movement.

HINGING THE AILERON.

Note : he control surfaces, including the ai-
lerons, elevators, and rudder, are prehinged
with hinges installed, but the hinges are not
glued in place. It is imperative that you prop-
erly adhere the hinges in place per the steps
that follow using a high-quality thin C/A glue.
1) Carefully remove the aileron from one
of the wing panels. Note the position of the
hinges.
2) Remove each hinge from the wing panel
and aileron and place a T-pin in the center of
each hinge. Slide each hinge into the wing
panel until the T-pin is snug against the wing
panel. his will help ensure an equal amount
of hinge is on either side of the hinge line
when the aileron is mounted to the aileron.
