Seagull Models SEA276 Assembly Manual page 18

P-51D MUSTANG
4) On the ire wall has the location for
the throttle pusshrod tube (pre-drill).
5) Slide the pushrod tube in the irewall
and guide it through the fuel tank mount.
Use medium C/A to glue the tube to the
irewall and the fuel tank mount.
6) Connect throttle pushrod to adjust-
able servo connector of the carburetor
arm as shown below. Trim any excess
pushrod wire using side cutters.
Use a 2.5mm hex wrench to tighten the
screw that secures the throttle pushrod
wire. Make sure to use threadlock on the
screw so it does not vibrate loose.
7) Position the engine between the
mounts. Use four M4x30mm machine
screws to secure the engine to the mount
as shown.
Pushrod wire.
Machine screw M4x30mm
18
Instruction Manual.
8) Connect the Z-bend in the 450mm
throttle pushrod to the outer hole of the
thottle servo arm.
COWLING.
1) Tape the cowl to the fuselage using
low-tack tape.
