Control Throws - Seagull Models SEA276 Assembly Manual

P-51D MUSTANG
With the wing attached to the fuselage,
all parts of the model installed ( ready to
ly), and empty fuel tanks, hold the mod-
el at the marked balance point with the
stabilizer level.
Lit the model. If the tail drops when
you lit, the model is "tail heavy" and you
must add weight* to the nose. If the nose
drops, it is "nose heavy" and you must
add weight* to the tail to balance.
*If possible, irst attempt to balance the
model by changing the position of the re-
ceiver battery and receiver. If you are un-
able to obtain good balance by doing so,
then it will be necessary to add weight to
the nose or tail to achieve the
proper balance point.
HIGH RATE
Ailerons:
Up: 13mm
Down: 10mm
Elevator:
Up: 18mm
Down: 18 mm
Rudder:
Right: 25mm
Let: 25 mm
Flaps:
Mid: 19mm
Landing: 38 mm
32

CONTROL THROWS.

Ailerons:
Up:
Down:
Elevator:
Up:
Down:
Rudder:
Right:
Let:
Instruction Manual.
103-114mm
LOW RATE
10mm
8mm
14mm
14 mm
20mm
20 mm
