4-Layer EN55022 Class B Radiated Emissions Compliant Evaluation Board for the
ADM2582E/ADM2587E
FEATURES
2.5 kV rms power and signal isolated RS-485/RS-422 transceiver
Printed circuit board (PCB) layout optimized for EN55022
radiated emissions according to the
Note
ADM2582E
passes EN55022 Class B (certification available)
ADM2587E
passes EN55022 Class B (certification available)
4-layer PCB layout that minimizes PCB material cost
Convenient connections for power and signal through screw
terminal blocks
Configurable as half duplex or full duplex
5 V or 3.3 V operation
Easily configurable through jumper connections
Test points for measuring all signals
EVALUATION KIT CONTENTS
EVAL-ADM2582EEBZ
board
DOCUMENTS NEEDED
AN-1349 Application Note
ADM2582E/ADM2587E
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Arrow.com.
Downloaded from
EVAL-ADM2582EEBZ/EVAL-ADM2587EEBZ User Guide
2.5 kV rms Signal and Power Isolated RS-485/RS-422
Transceivers with ±15 kV ESD Protection
AN-1349 Application
or
EVAL-ADM2587EEBZ
evaluation
data sheet
EVALUATION BOARD PHOTOGRAPH
GENERAL DESCRIPTION
The
ADM2582E/ADM2587E
the
ADM2582E
and
RS-422 transceivers. Screw terminal blocks provide convenient
connections for the power and signal connections. The evaluation
board is easily configured through jumper connections. The board
can be used in half-duplex or full-duplex configurations and has
a 120 Ω termination resistor fitted on the receiver input. The
evaluation board can be used with either the
device or the
ADM2587E
are enabled and disabled by jumper connections. Test points are
included on the power and signal lines on both sides of the
isolation barrier.
EN55022 RADIATED EMISSIONS
The
ADM2582E/ADM2587E
reduce emissions generated by the high frequency switching
elements used by the isoPower® technology to transfer power
through the
ADM2582E/ADM2587E
The layout of the evaluation board is generated using the guidelines
provided in the
AN-1349 Application
Guidelines to Minimize Radiated Emissions on the ADM2582E/
ADM2587E
RS-485/RS-422 Transceivers. The
ADM2582E
evaluation boards are tested and certified to pass
EN55022 Class B.
Figure 1.
Rev. D | Page 1 of 13
evaluation board can easily evaluate
ADM2587E
power and signal isolated RS-485/
ADM2582E
500 kbps device. The driver and receiver
evaluation board is designed to
integrated transformer.
Note, PCB Implementation
ADM2587E
UG-044
16 Mbps
and
