Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Harness from Driver Side Door
10-pin Gray or White Connector
Dash Fuse
Box (1C)
5 4 3 2 1
9 8 7 6
13 12 11 10
(+) Brake: Blue, pin 13
D2D Port
(+) Brake Status Input
(-) Lock Output
(-) Unlock Output
(-) Hood Pin Input
(AC) Tach Input
(-) Parking Lights Output
(+) Accessory Output
(+) 12V Input
(+) Starter 1 Output
(+) Starter 2 Output
(+) Ignition 2 Output
(+) Ignition 1 Input/Output
(-) Ground (-) Ground
6 403.TL7 2.36 2011 Toyota Tacoma (G Key)
©2023 VOXX•DEI LLC. All rights reserved.
(-) Unlock/Disarm:
Green/Black, pin 8
10 9 8 7 6
5 4 3 2 1
Tach Output:
(-) Lock/Arm:
Black/White, pin 9
Violet, pin 4
Hood Pin
Ignition Connector
4 3 2 1
8 7 6 5
Refer to the Vehicle connections
section for wire and connector
details.
Diagnostic Connector OBDII
SIL: White,
HS CAN High:
pin 7
Yellow/Black, pin 6
1 8
9 16
HS CAN Low:
Blue/White,
pin 14
HS CAN High: Tan/Black: 3
(-) Parking Lights:
Green, pin 18
10 9 8 7 6 5 4 3 2 1
20 19 18 17 16 15 14 13 12 11
SIL Data Output: Yellow/Black: 10
Headlight Switch
).
HS CAN Low: Tan: 4
XKD2D65
9: Pink:
(+) Ignition
Input
