Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
CAN B Low: White, pin 7
connector side view)
1
8
CAN B High:
(-) Ground: Black or
White/Orange,
Black Striped, pin 4
pin 6
(MUX) Ignition:
Violet/Brown, pin 2
6
933.CHRYSLER 7.34.195.3 2005 Chrysler 300/300c
©2022 VOXX•DEI LLC. All rights reserved.
Sentry Key Module
(black 8-pin conn.,
Ignition Switch
(black 5 or 6-pin conn.)
Refer to the Optional starter
disable connection section for
relay and connection details.
1
(+) Start: Pin 4
(+) Ignition:
Pink/White, pin 3
"Vehicle connections" section
for wire and connector details.
Siren
Hood Pin
Refer to the
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
A
this installation.
(MUX) Ignition Output: Violet/Brown: 6
(-) GWA Output: Red/White: 4
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
(+) 12V Input: Blue/Red: 2
(+) Ignition Output: Blue: 3
(+) Parking Light Output: White: 5 & 11
(+) 12V Input: Red: 6 & 12
(+) 12V Input: Lt. Green/Red: 7
(+) Start Output: Lt. Green: 8
(-) Ground: Black: 10
).
module can also be used for
IMPORTANT:
Position the
fuses correctly!
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
