Vehicle connections

The connection information listed below is specific to the 2011 Toyota Tacoma (G Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
8 403.TL7 2.36 2011 Toyota Tacoma (G Key)
©2023 VOXX•DEI LLC. All rights reserved.
Description
No Connection
No Connection
(DATA) HS CAN High
(DATA) HS CAN Low
No Connection
No Connection
Relay N.O. No Connection
Relay COM. SIL Interrupt
Relay N.C. SIL Interrupt
Relay N.C. Auto Light Interrupt
Relay COM. Auto Light Interrupt
Relay N.O. No Connection
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
(-) W2W Only - E-Brake Output
No Connection
(-) W2W Only - Door Output
(-) W2W Only - Trunk Output
[2]
(AC) W2W Only - Tach Output
(+) W2W Only - Brake Output
No Connection
No Connection
No Connection
(Data) SIL
(Data) RDA
(-) W2W Only - Hood Output
Description
Connects To
Wire Location
No Connection
No Connection
data link connector, white 16 pin plug, pin 6
data link connector, white 16 pin plug, pin 14
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
ignition switch, white 8 pin plug, pin 5
Connects To
Wire Location
Remote Starter
No Connection
Remote Starter
Remote Starter
data link connector, white 16 pin plug, pin 9
Remote Starter
No Connection
No Connection
No Connection
data link connector, white 16 pin plug, pin 7
No Connection
Remote Starter
Connects To
Wire Location
(+/-) Wire Color
data yellow/black
data blue/white
+ white/red (30A)
(chassis ground)
(+/-) Wire Color
ac black/white
data white
(+/-) Wire Color
