Directechs DIRECTED DB3 Installation Manual page 10

Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire
12 Volts
Accessory
Brake Wire
Factory Alarm Arm
Factory Alarm Disarm
Hood Pin
Ignition
Parking Lights -
Second Ignition
Second Starter
Starter
Tachometer
Tachometer
10 403.TL7 2.36 2011 Toyota Tacoma (G Key)
©2023 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
ignition switch, white 8 pin plug, pin 5
ignition switch, white 8 pin plug, pin 2
dash fuse box, white 13 pin plug (1D), pin 13
driver kick, white 10 pin plug, pin 4
driver kick, white 10 pin plug, pin 8
Not Applicable
ignition switch, white 8 pin plug, pin 6
headlight switch, white 20 pin plug, pin 18
ignition switch, white 8 pin plug, pin 1
ignition switch, white 8 pin plug, pin 3
ignition switch, white 8 pin plug, pin 7
data link connector, white 16 pin plug, pin 9
data link connector, white 16 pin plug, pin 9
(+/-) Wire Color
+ white/red (30A)
+ white/green
+ blue
- violet (driver door key lock)
double - green/black (driver door key unlock)
+ black/red
- green
+ blue/yellow
+ black/white
+ green/black
ac black/white
ac black/white
