Model W1678 (For Machines Mfd. Since 02/24)
5 HP 26" DOUBLE DRUM SANDER
Product Dimensions
Weight.......................................................................................................... 435 lbs.
Width (side‐to‐side) x Depth (front‐to‐back) x Height................................... 50 x 37 x 44‐1/2 in.
Footprint (Length x Width)......................................................................... 36 x 23‐3/4 in.
Shipping Dimensions
Type.................................................................................. Cardboard Box on Metal Skids
Content........................................................................................................ Machine
Weight.......................................................................................................... 546 lbs.
Length x Width x Height........................................................................... 41 x 41 x 41 in.
Electrical
Power Requirement.................................................................... 220V, Single‐Phase, 60 Hz
Full‐Load Current Rating......................................................................................... 27A
Minimum Circuit Size............................................................................................. 30A
Connection Type......................................................................................... Cord & Plug
Power Cord Included.............................................................................................. Yes
Power Cord Length.............................................................................................. 14 ft.
Power Cord Gauge............................................................................................ 12 AWG
Plug Included........................................................................................................ No
Recommended Plug Type...................................................................................... L6‐30
Switch Type....................................................... Control Panel w/Magnetic Switch Protection
Motors
Main
Horsepower................................................................................................. 5 HP
Phase.............................................................................................. Single‐Phase
Amps.......................................................................................................... 25A
Speed.................................................................................................. 3450 RPM
Type......................................................................... TEFC Capacitor‐Start Induction
Power Transfer ..................................................................................... Belt Drive
Bearings................................................................. Sealed & Permanently Lubricated
Centrifugal Switch/Contacts Type................................................................. External
Feed
Horsepower.............................................................................................. 1/3 HP
Phase.............................................................................................. Single‐Phase
Amps........................................................................................................... 2A
Speed..................................................................................................... 60 RPM
Type.................................................................................................... Universal
Power Transfer ................................................................................... Chain Drive
Bearings................................................................. Sealed & Permanently Lubricated
MODEL W1678
MODEL W1678
5 HP 26" DRUM SANDER
Model W1678 Machine Specifications, Page 1 of 2
