Operations; General - Shop fox W1678 Manual

General

This machine will perform many types of operations
that are beyond the scope of this manual. Many of these
operations can be dangerous or deadly if performed
incorrectly.
The instructions in this section are written with the
understanding that the operator has the necessary
knowledge and skills to operate this machine. If at any
time you are experiencing difficulties performing any
operation, stop using the machine!
The overview below provides the novice machine operator
with a basic understanding of how the machine is used
during operation, so the machine controls/components
discussed later in this manual are easier to understand.
Due to its generic nature, this overview is NOT intended
to be an instructional guide.
To complete a typical operation, the operator does the
following:
1. Examines workpiece to make sure it is suitable for
sanding and determines which sandpaper grit to use.
2. Verifies workpiece has necessary outfeed clearance
and support. If workpiece is overly long and difficult
to handle, operator uses a roller support stand and/
or an assistant to assist with operation.
3. Adjusts table height to approximate workpiece
thickness.
Note: During initial pass with a new workpiece,
operator adjusts table height as necessary so
workpiece only makes light contact with sanding
drums and does not overload sander.
4. Puts on safety glasses and respirator
5. Starts dust collection system, then drum sander.
Waits for sanding drums to reach fulls speed, then
sets conveyor speed for specific type and finish of
workpiece.
Model W1678 (For Machines Mfd. Since 02/24)

OPERATIONS

-22-
To reduce your risk of serious injury
or damage to the machine, read this
entire manual BEFORE using machine.
To reduce the risk of eye injury and
long-term respiratory damage, always
wear safety glasses and a respirator
while operating this machine.
If you are an inexperienced operator,
we strongly recommend that you read
books or trade articles, or seek training
from an experienced operator of this
type of machinery before performing
unfamiliar operations. Above all, safety
must come first!
Loose hair, clothing, or
jewelry could get caught
in machinery and cause
serious personal injury.
Keep these items away
from moving parts at all
times to reduce this risk.
