4-Port 12G SDI Card (Discontinued)

The 4-port 12G card has 5 BNC connectors:
Note: Refer to imprinted labels (1 through 4) and R for proper cable connection.
•
4 SDI Ports (1-4): 12G x UHD1080 video formats; audio 16-Channel, 24-bit SDI
embedded, 48 kHz synchronous for 2 input operation. Active loop-through is not
supported.
•
Input Reference (R): LTC timecode input
Master Template User's Guide
Lightspeed Live Server Specifications
R connector
for LTC
