Creating Live and Tape Capture Workflows
206
Creating a Tape Capture Workflow
Stitch Clips. When checked, stitches the aggregated content from all captured clips
into a direct-converted output file. See Stitch Behavior, below.
Stitch Clip Base Name. Specifies the base name to use in job names and the Base
Name part of the file name pattern. When blank,
name.
Stitch Behavior. Specifies the stitched file behavior: Direct Convert, which can not be
changed. Creates a self-contained output file for the Primary and/or Secondary
outputs, which contains the aggregated content from all captured clips in the order
specified by the user.
The output file can be used by a downstream action for additional processing.
Allow Secondary Output to be Disabled. Check to add the option to disable the
secondary output in the Tape Capture web application. When selected, the "Disable
Secondary Output" option is added to the Tape Capture web app Capture Clips dialog.
Note: When Allow Secondary Output to be Disabled is selected, no downstream
processing can be done for the secondary output. With this enabled, you cannot save
the workflow if it is set to process the secondary output.
When you need to have downstream actions process the secondary output, but you
want the option to disable the secondary output in the Tape Capture web app, add the
Poster Frame secondary output so that can be selected in the web app as the disabled
option.
You must create one or more MP4 secondary outputs when Allow Secondary Output to
be Disabled is selected, in order to have the option to enable and create a secondary
output in the Tape Capture web app.
Generate Variables. Select which variables to generate:
Is Output Stitched. When checked, enables the ability to detect if the output is
stitched or not. Select or create a True/False variable to generate, which is used in a
downstream action to execute the workflow based on the result. (Use a Decide action
to test the variable and perform one branch or another.)
Primary Configuration. When checked, generates the specified variable to enable
downstream actions to determine which configuration was used in this action. The
variable contains the primary configuration that was selected by an operator for this
job, in the Record panel of the Tape Capture Web app, which is selected from the menu
that displays all of the primary configurations you have configured here in the Tape
action to be available to the operator during tape capture operations.
Secondary Configuration. When checked, generates the specified variable to enable
downstream actions to determine which configuration was used in this action. The
variable contains the secondary configuration that was selected by an operator for this
job, in the Record panel of the Tape Capture Web app, which is selected from the menu
that displays all of the secondary configurations you have configured here in the Tape
action to be available to the operator during tape capture operations.
StitchedClip is the default base
