Live Capture Single Server Licensing; Required Lightspeed Live Capture Licenses; Optional Lightspeed Live Capture Licenses - Telestream Lightspeed Live Capture User Manual

Live Capture Single Server Licensing

This topic describes required and optional licenses for a single-server Live Capture
system for all models of Lightspeed Live servers, as well as Live Capture installed on a
virtual machine (VM).
To obtain licenses or obtain licensing information or assistance, see
| Information |
Note: License files may contain one or more license policies, and there may more
than one license file in a Vantage domain. The number of license files is immaterial;
only the license policies within the file(s) are relevant. License installation is described
in the Domain Management Guide.
Lightspeed Live Capture license files are added to the Vantage domain, where the
license policies are extracted from the file(s) and stored in the Vantage database for
utilization.
You use the Vantage Management Console to add, view, and manage licenses. See the
Vantage Domain Management Guide, which is available directly in the console, for
assistance.

Required Lightspeed Live Capture Licenses

A Lightspeed Live Capture license is required for all Live Capture systems.

Optional Lightspeed Live Capture Licenses

•
Basic Single File Analysis (LSL-ANLZ-SW)—includes single-file analysis for curtains,
letter-boxing, Telecine, black detection, slate/spot detection, macro-blocking, loud-
ness measurement with dialog detection and gating controls for compliance with
CALM Act, ATSC A/85, BS-1770-2 and EBU R128, and more. Includes PSNR measure-
ment for two-file QC analysis. Does not include first year of Software Annual Main-
tenance and Support which must be ordered at time of purchase. Refer to
Maintenance section for more information. Intended for use on Live Capture sys-
tems while no ingests are being performed.
•
Extended Single File Analysis (LSL-ANLYZ-PRO-SW)—Includes all capabilities of
Basic Single File Analysis, with additional capabilities for Dolby Atmos audio loud-
ness, Dolby Vision metadata extraction, Dolby E audio detection and analysis, com-
pliance checking, PDF reporting, and integration with MediaInfo for extended
media properties. Intended for use on Live Capture system while no ingests are
being performed.
•
JPEG2000 codec option for Lightspeed Live Capture (LS-LIVE-CAP-J2K)—enables
JPEG2000 SD/HD recording up to 1080p60.
•
MPEG2-TS with Manzanita Option for Live Capture (LS-LIVE-TS-OPTION)—providing
support for MPEG2 Transport Stream container with Manzanita multiplexing. Sup-
ports Live Capture's MPEG-2 and x264 video codecs.
