Configuring SDI Sources

All SDI sources are permanent—you can't create or delete them. For each SDI source
port on the server (model dependent), an SDI source displays in the Sources panel.
Note: If you have implemented RouteMaster for SDI source control, if you are
changing the destination, you should de-activate associated workflows and then
restart them. See the Live Schedule Pro User Guide for selecting RouteMaster sources.
In a Live Capture array, you should name each Lightspeed Live Server's SDI ports with a
unique name to avoid confusion—for example, add the Lightspeed Live Server name
as a prefix: Lightspeed1-SDI-1, or on a C5, Lightspeed1-SDI-0:1.
To modify an SDI source configuration, select it in the Sources panel to display its
Preview panel.
Note: While an SDI source is being captured, you can only edit the source's name and
description. Some controls display only when you enable advanced mode. Select
Settings in the main menu
Settings.
Click the Edit icon
Lightspeed Live Capture User Guide
to display the System Settings panel. See
to display its Configure Source dialog:
Managing Video Sources
Configuring SDI Sources
Managing System
Advanced Mode settings—
enable Advanced Mode in
the System Settings panel.
243
