- Variable: Select to choose and add a variable to the file name.
- Date: Select to add the date as part of the file name.
- Time: Select to add the time as part of the file name.
The Variable token is replaced by the value it holds when the action executes. The
variable should be set prior to execution of this action. For example, if a Variable token
named ISCI is given the value
the filename pattern it is replaced with that value.
Select Media Nickname. Specifies the nickname for this media.
Add. Create a new Configuration Template, by first choosing the template's output
container format from the Add menu. Specify a container type, enter a unique name in
the container's Config Name field and configure container details in the panel on the
right. Now, click on the video and audio streams on the left and configure them as well,
in the panel on the right. Add all of the output configurations that you want to have
available in the Tape Capture web app.
After logging clips, click the Capture button in the Tape Capture web app to select the
primary output container format you want to use for the capture operation.
Delete. Click the X icon on the right to delete the output from this action.

Settings Panel

Specify settings to use for each output configuration. Binding a parameter to a variable
makes the parameter configurable directly in the Tape Capture web app.
Generate Variables
Ignore Lost Frames. When enabled, allows capture to continue recording if a Loss of
Signal | FIFO overrun/overflow | Loss of RS422 condition is encountered or if video
format changes are encountered. If disabled, the capture will stop when it encounters
these conditions. Enabling Ignore Lost Frames should not be necessary in most cases.
For LOS details, see.
Pre-Roll Duration. Specifies the number of seconds that tape rolls before a scheduled
recording begins. You can also assign a variable defined elsewhere in the workflow.
Note: Setting Pre-Roll Duration to 0 (zero) may have a use in some cases, such as
capturing digital sources. A 0 (zero) setting could cause issues when capturing from
tape sources. The default Pre-Roll is 3, which often works fine for a tape source.
Post-Roll Duration. Specifies the number of seconds that tape rolls after a scheduled
recording ends. You can also assign a variable defined elsewhere in the workflow. Note
that the VTR stops only after all frames have been captured, so post-roll may continue
longer than the duration you specify.
Timecode Override Enable. When checked, activates and overrides the Input Source
timecode with the one entered in the Timecode Override control. When enabled,
