Allow Manual Control option enabled. See
above for behavior when the Allow Manual Control option is enabled.

Expected Labels

Enable Labels to enable operators to update label values in the Live Capture web
application and process them in the Capture action or downstream in the workflow.
Labels can be used in downstream Vantage actions, typically to update or add
properties in Interplay, or transformed into text or XML for out-of-band delivery.
Labels that are enabled can be configured in the Live Capture web app Channel
Options > Configure Labels dialog. Label creation and design is performed in the
Vantage Management Console.
For more information on creating labels, search the Lightspeed Live Capture User Guide
for Create Labels and Variables for the Tape and Capture
Live Capture web application, search for Channel Options.
Note: If label parameters are changed or modified in the Vantage Management
Console, the changes need to be applied to Capture actions that use them, so that
they display correctly in the Live Capture web app.
To apply label updates to a Capture action, you must:
1. Put the workflow into edit mode and display the Capture action inspector.
2. In Expected Labels, disable the target label(s); then re-enable them.
3. Save the action and re-activate the workflow.
Now, the updated label(s) will display correctly in the Live Capture web app.

Configuring Trigger Settings

Use the Trigger panel to select the method you want to use to control live video input,
and to configure trigger settings.
You can implement the following triggers: DAI |Manual | Recurring Segment | CalDAV
Calendar | Web Service. Proceed to the appropriate topic for configuration details,
following.
Note: When you use Live Schedule to schedule recordings, only Web Service, Manual,
or Recurring Segment triggers are supported.
Select. Choose DAI |Manual | Recurring Segment | CalDAV Calendar | Web Service.
Proceed to the appropriate topic for configuration details, following.

DAI Triggers

The DAI (Dynamic Ad Insertion) Trigger enables automatic recording to start and stop
based on incoming SCTE-104 markers contained in the VANC data stream of the
workflow's SDI input. Recording begins when a Start Program marker is detected and
stops when an associated Stop Program marker with an Event ID that matches the Start
Program's ID is detected. See details below.
Lightspeed Live Capture User Guide
Creating Live and Tape Capture Workflows
Creating a Live Capture Workflow
Operation When Restrict Input is Enabled
Actions. To update Labels in the
191
