SPG9000
Installation and Safety Instructions
P00010606A
March 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPG9000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telestream SPG9000

Summary of Contents for Telestream SPG9000

  • Page 1 SPG9000 Installation and Safety Instructions P00010606A March 2023...
  • Page 2 Telestream shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Telestream service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
  • Page 3 ACCEPTANCE OF THE AGREEMENT TERMS. IF THESE TERMS ARE NOT ACCEPTABLE, THE UNUSED PROGRAM AND ANY ACCOMPANYING DOCUMENTATION SHOULD BE RETURNED PROMPTLY TO TELESTREAM FOR A FULL REFUND OF THE LICENSE FEE PAID. (FOR INFORMATION REGARDING THE RETURN OF PROGRAMS ENCODED OR INCORPORATED WITHIN EQUIPMENT, CONTACT THE NEAREST TELESTREAM SALES OFFICE.)
  • Page 4 Title to the Program and all copies thereof, but not the media on which the Program or copies may reside, shall be and remain with Telestream or others for whom Telestream has obtained a respective licensing right. Customer shall pay when due all property...
  • Page 5 Telestream. This Agreement and the license granted herein shall be governed by the laws of the state of California. All questions regarding this Agreement or the license granted herein should be directed to the nearest Telestream Sales Office. SPG9000 Installation and Safety Instructions...

  • Page 6: Table Of Contents

    Table of Contents Important Compliance and Safety Information Preface Installation Operating Requirements Rack Installation Power Connection Physical Connections Rear Panel Connectors SFP Module Installation Basic Operation Front Panel Controls Network Connection Web User Interface SPG9000 Installation and Safety Instructions...

  • Page 7: Important Compliance And Safety Information

    Environmental Perchlorate Materials: this product contains one or more type CR lithium batteries. According to the state of California, CR lithium batteries are classified as perchlorate materials and require special handling. www.dtsc.ca.gov/hazardouswaste/perchlorate for additional information. SPG9000 Installation and Safety Instructions...
  • Page 8 SLOVENIA, SPAIN, SWEDEN, ICELAND, LIECHTENSTEIN, NORWAY, UNITED KINGDOM, SWITZERLAND Declaration of Conformity Marking by the “CE” symbol indicates compliance with the Essential Requirements of the EMC Directive of the European Union 2014/30/EU This equipment meets the following conformance standards: SPG9000 Installation and Safety Instructions...
  • Page 9 SPG9000 Installation and Safety Instructions...
  • Page 10 Restriction of Hazardous Substances This product is classified as an industrial monitoring and control instrument, and is required to comply with the substance restrictions of the RoHS 3 Directives 2011/65/EU and EU 2015/863. Korea Compliance Statement SPG9000 Installation and Safety Instructions...
  • Page 11 Only qualified personnel who are aware of the hazards involved should remove the cover for repair, maintenance, or adjustment. Before use, always check the product with a known source to be sure it is operating correctly. SPG9000 Installation and Safety Instructions...
  • Page 12 Use Only Specified Replacement Parts Do not operate in wet/damp conditions: Be aware that condensation may occur if a unit is moved from a cold to a warm environment. Do not operate in an explosive atmosphere. SPG9000 Installation and Safety Instructions...
  • Page 13 Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries. Use only the Telestream rackmount hardware specified for this product. Service Safety Summary The Service safety summary section contains additional information required to safely perform service on the product.
  • Page 14 ADVERTENCIA: Se pueden producir lesiones personales o daños al instrumento si el instrumento no está debidamente asegurado en el bastidor del equipo. WARNUNG: Personenschäden oder Schäden am Gerät können auftreten, wenn das Gerät nicht ordnungsgemäß im Gerätegestell befestigt ist. SPG9000 Installation and Safety Instructions...
  • Page 15 AVISO: Para evitar ferimentos ao remover o produto do rack, não puxe o produto com força e abruptamente do rack. Puxe com a força mínima necessária para mover o instrumento com um movimento consistente e uniforme. SPG9000 Installation and Safety Instructions...
  • Page 16 ATTENTION: Des dommages peuvent être produits par la mise sous tension dans des plages de température en dehors des valeurs spécifiées. ATTENZIONE: Non accendere lo strumento se la temperatura ambiente è al di fuori dell’intervallo specificato in quanto si possono provocare danni. SPG9000 Installation and Safety Instructions...
  • Page 17 N'installez pas ou ne retirez pas un module d'alimentation lorsqu'un cordon d'alimentation est connecté à ce module. ATTENZIONE: lo strumento non dispone di un interruttore di alimentazione. Quando si collega il cavo di alimentazione al connettore di linea CA, lo strumento si accende. Non SPG9000 Installation and Safety Instructions...
  • Page 18 CUIDADO: O instrumento não possui um interruptor de alimentação. Quando você conecta o cabo de alimentação ao conector de linha CA, o instrumento liga. Não instale ou remova um módulo de fonte de alimentação quando um cabo de alimentação estiver conectado a esse módulo. SPG9000 Installation and Safety Instructions...

  • Page 19: Preface

    Preface Preface This manual describes how to install the SPG9000 and basic start up settings. Safety information related to installation is also provided. Where to Find More Information The full User Manual, Release Notes, and other information about your product are available for download at www.telestream.net/video/resources.htm.
  • Page 20 848 Gold Flat Road, Suite 1 Nevada City, CA. USA 95959 International Website: www.telestream.net Distributor Support See the Telestream website for your regional authorized Telestream distributor. Telestream Technical Email: techwriter@telestream.net Writers If you have comments or suggestions about improving this document or other Telestream documents—or if you've discovered an error or omission, please email us.

  • Page 21: Installation

    This section has the basic requirements of how to prepare the equipment for use. This includes operational limits for the equipment, how to install it in a rack, and how to connect power. For details on these topics, refer to the SPG9000 User Manual. Operating Requirements This section provides the environmental and power operating requirements for safe operation of the instrument.
  • Page 22 100 to 240 VAC +/- 10% WARNING: To reduce the risk of fire and shock, ensure that the mains supply voltage fluctuations do not exceed 10% of the operating voltage range. Line frequency 50/60 Hz SPG9000 Installation and Safety Instructions...

  • Page 23: Rack Installation

    WARNING: Personal injury or damage to the instrument can occur if the instrument is not properly secured in the equipment rack. When you order Option SPG9000-RACK, the instrument is configured at shipment for use in an equipment rack. Refer to the Rackmount Slides and Rails Kit Instructions that was supplied with the instrument for instructions on how to install the rack mounting hardware.
  • Page 24 1. Loosen the knob screws that attach the front of the instrument to the rack. 2. Gently pull the instrument toward you until you can reach the levers at the rear of the instrument. SPG9000 Installation and Safety Instructions...
  • Page 25 Installation Rack Installation 3. Tilt both lever handles upward simultaneously to allow them to clear the stops. 4. Pull the instrument past the stops and out of the rack. SPG9000 Installation and Safety Instructions...

  • Page 26: Power Connection

    When ordered with Option SPG9000-SPW, a single power supply module is installed in the instrument. With Option SPG9000-DPW, a second hot-swappable redundant (backup) power supply module is also installed. When two power supply modules are installed in the instrument, one is configured to be the primary supply and the other is configured to be the backup supply.
  • Page 27 Note: This capability is only available when Option SPG9000-DPW is installed. After the instrument powers on, configure the instrument for the preferred (active) supply. See the SPG9000 User Manual for detailed information about how to operate the instrument with two power supplies.

  • Page 28: Physical Connections

    Physical Connections This section explains the basics of the connections available on the equipment. For details of the connections and their use, refer to the SPG9000 User Manual. Rear Panel Connectors The illustration shows the external connections on the rear panel of the SPG9000 instrument.
  • Page 29 LTC/GPI D-sub connector (DE-15) is for Linear Time Code (LTC) input/ outputs and GPI on a single cable. The Option SPG9000-XLR breakout cable can be used to send the LTC 1-4 signals from this connector to XLR connectors.

  • Page 30: Sfp Module Installation

    SFP Module Installation SFP Module Installation The SPG9000 has two pairs of sockets (4 sockets total) that can be used with SFP transceiver modules for optical network connections. When Option SPG9000-PTP is installed, the SFP+ sockets labeled PTP 1 and PTP 2 are enabled. They can use SFP modules for 1 Gbps or 10 Gbps line rates.

  • Page 31: Basic Operation

    Basic Operation Front Panel Controls Basic Operation This section describes the general requirements for network connection and how to use the equipment. For details of how to utilize the SPG9000, refer to the SPG9000 User Manual. Front Panel Controls Display The display is used for status and configuration menus for front-panel operation.
  • Page 32 Press to configure the PTP (Precision Time Protocol) parameters for the two PTP instances. Press the button repeatedly to cycle between the configuration menu for PTP 1 and PTP 2. Option SPG9000-PTP required. OUTPUTS Use these buttons to access menus for configuring the signal outputs.
  • Page 33 Press to configure the video parameters, embedded audio, and ancillary data for the selected SDI output. Press the SDI button repeatedly to cycle between the menus for each of the SDI 1 to SDI 4 outputs. Option SPG9000-SDI required. SYSTEM Button Press to access the SYSTEM menu to configure and view various system-wide settings.
  • Page 34 STATUS light that matches the status shown on the PWR 1 and PWR 2 indicators. FAULT Indicator The FAULT indicator lights when there is a problem with the instrument hardware. Note: You can view descriptions of the active alerts and faults using the STATUS menu. SPG9000 Installation and Safety Instructions...

  • Page 35: Network Connection

    6. Press the left or right arrow button to change the current item to "Enable” and press the ENTER button. 7. Press the down arrow button until the SYSTEM : NETWORK : MGMT : IP ADDRESS sub-menu is highlighted. The address granted from the DHCP servers is displayed. SPG9000 Installation and Safety Instructions...
  • Page 36 6. When the address is entered, exit edit mode: – To accept the entered address and exit edit mode, press the ENTER button. – To cancel the entered address (revert to the previous address) and exit edit mode, press the BACK button. SPG9000 Installation and Safety Instructions...
  • Page 37 6. When the address is entered, exit edit mode: – To accept the entered address and exit edit mode, press the ENTER button. – To cancel the entered address (revert to the previous address) and exit edit mode, press the BACK button. SPG9000 Installation and Safety Instructions...

  • Page 38: Web User Interface

    When you enter the IP address of the instrument in a supported web browser, the web interface opens. Select the tabs to access the instrument settings and controls as you would using the front panel buttons. SPG9000 Installation and Safety Instructions...
