- Page 1 303-215-9171 CO2 Laser Tube Replacement Fusion Maker - Fusion Edge - Fusion Pro 24 & 36 Parts Required Tools/ Materials Required • Dependent on laser wattage • 5/32” Allen Wrench • Phillips Head Screwdriver 07/2023...
- Page 2 17000 - CO2 Laser Tube Replacement CO2 Laser Tube 5. Disconnect the data cable on the left side of the laser tube: Replacement CO2 Laser Tube Removal 1. Turn off the engraver. 2. Disconnect engraver from power. 3. Depending on the model of engraver, remove the back or lower rear panel of the engraver to uncover the laser bay: 6.
- Page 3 17000 - CO2 Laser Tube Replacement CO2 Laser Tube Installation The green-capped screws are captive screws and cannot be fully removed from 1. Install the laser tube into the laser bay, the laser tube mounting brackets. When ensuring that the guide pin on the the screws have been fully loosened, they engraver chassis enters the opening on will pop away from the laser tube mount-...
- Page 4 If further assistance is required, please contact Epilog Laser Technical Support by phone at 303-215-9171, or by email at tech@epiloglaser.com. 4. Connect the laser tube power harness from the main electrical harness of the engraver.
