Canon imagePROGRAF iPF825 Service Manual page 51

[GL2 Settings]
[Quality Manager] [Color Mode]
[Print Quality]
[Input Resolution]
[Print (Economy)]
[Paper Manager] [Paper Source]
[Margin]
[Conserve Paper]
[Auto Rotate]
[Nesting]
[Line & Pen Manager] [Enable merge]
[Pen Setup]
[Smoothing]
[ThickenFineLines]
[AdjustFaintLines]
[ProcessingOption] [Warning]
[On-the-Fly]
[PageSizeProcess1]
[PageSizeProcess2]
Setting Item
[Monochrome]
[Color (CAD) 1]
[Color (CAD) 2]
[Color (CAD) 3]
[Color (CAD) 4]
[Color (CAD) 5]
[Color (CAD) 6]
[Use Nesting]
[Nesting WaitTime]
[Cut Lines]
[Select Palette]
[Define Palette]
[Reset Palette]
T-1-20
Description/Instructions
Print by the monochrome.
Print by the standard color.
Print by the bright color.
Print by the color emulated the Canon iPF500/iPF600/iPF700/iPF510/iPF610/iPF710/
iPF605/iPF720/iPF810/iPF820.
Print by the color emulated the HP Designjet 500/800.
Print by the color emulated the HP Designjet 1000.
Print by the color emulated the HP Designjet 4000/4050.
Select the print quality.
Choose the printer input resolution from between [600dpi] and [300dpi].
Prints with a lower grade of print than normal, but with less ink consumption. Select [ON]
to economize on inks.
Select how to feed paper for printing on the HP-GL/2.
Set the top/bottom and left/right margins of the paper. For cut-sheet, the trailing edge
margin is 23mm.
However, if the leading edge margin is set with [Paper Details], that value has priority.
Prints by economizing on paper.
If a document has its long side shorter than the roll width, the page rotates by 90 degrees
automatically to economize on paper. If a document contains horizontally long data such
that it has its long side longer than the roll width and its short side shorter than the roll width,
the page rotates 90 degrees to print within the boundaries of the paper.
HP RTL cannot rotate.
In case of HP RTL image, the image may be truncated or a blank paper may be ejected
because the image cannot be rotated even if the paper size is rotated by 90 degrees. In that
case, set [Auto Rotate] to [Off].
Select [On] to print pages when they are tiled fully to the roll width, instead of printing them
one by one.
Set the time to elapse before printing.
Select [On] to print perforated lines between pages.
When lines overlap, set whether to merge or overwrite the colors of the overlapping lines.
Select [Off] to overwrite with the line printed later. Select [On] to merge all overlapping
colors.
Select the value related to pen from [Software], [Palette A], [Palette B], or [Factory].
Select [Software] to print according to the application side instruction. Select [Palette A] or
[Palette B] to print with value set by [Define Palette].
Set [Width], [Color], and [Line Attributes] for the palette's [Pen Number]. Select [Factory]
to check the value when [Factory] is selected for [Select Palette].
For [Line Attributes], select the shape of line end and joint between lines as [No Setting] or
[Circle Setting].
Return the [Define Palette] settings to factory settings.
Choose whether to draw an arc with a smooth curve or with a polygon.
Select [On] to print thin lines clearly.
If thin lines print in a tint of color varied from other patterns, selecting [Off] may provide
the print result as intended, though the thin lines may print, interrupted, depending on the
color.
Select [On] to display warnings during GL2.
In printing data consisting solely of HP RTL, if the data is slow to print, select [On] to
expedite the time at which the data starts printing. Verify the print result to make sure that
images are not chipped in this case.
Normally, an image is printed inside margins necessary for printing, but if the image data
itself has margins, the print position will not be offset when this is set [On].
Select [On] to determine the paper size based on the drawing area.
Chapter 1
1-37
