Canon imagePROGRAF iPF825 Service Manual page 54

Chapter 1
[System Setup]
[Warning]
[Keep Paper Size]
[Paper Size Basis]
[Roll Switching]
[TrimEdge Reload]
[Noz. Check Freq.]
[CarriageScanWdth]
[Sleep Timer]
[Length Unit]
[Time Zone]
[Date Format]
[Date & Time]
[Language]
[Contrast Adj.]
[Reset PaprSetngs]
[Erase HDD Data]
[Output Method]
[Save and Print]
[Save: Common Box]
[Show Job Log]
1-40
Setting Item
[Buzzer]
[Detect Mismatch]
[Sht Selection 1]
[Sht Selection 2]
[Use Optional Size]
[No RollSwitching]
[Date]
[Time]
[High Speed]
[Secure High Spd.]
[Secure]
[Print]
[Print(auto delete)]
[Save in mail box]
T-1-24
Description/Instructions
Set the buzzer. Choose On for the buzzer to sound once for warnings and three times for errors.
Choose Warning for notification (display of a warning message) during printing if the paper
type specified in the printer menu does not match the paper type in the printer driver. Choose
None to continue print without notification. Choose Pause to have printing paused under these
circumstances. In this case, you can continue printing by pressing the Online button.
Choose On to use the paper size setting as the basis for printing instead of other settings. The
margin setting of the printer menu will be used instead of the margin setting of the printer driver
if the latter is smaller, which may prevent text or images in the margin from being printed.
Choose Off to use the printer driver settings instead. Even if the margin setting of the printer
driver is smaller than that of the printer driver, text or images will not be cut off. However, this
requires longer paper because the actual margin will be equal to the margin setting of the printer
driver plus the margin setting of the printer menu.
Select which size is to be recognized, [ISO A3+] or [13"x19"(Super B)], when the detected size
of the cut sheet is between these sizes.
Select which size is to be recognized, [ISO B1] or [28"x40"(ANSI F)], when the detected size
of the cut sheet is between these sizes.
Choose the paper size that can minimize margin of the paper.
Print from paper loaded on the platen.
Select whether cut the leading edge of the paper when the paper at the standby position has
loaded. Cut it when the roller trace at the standby position attract attention. Choose On to cut it
everytime when the paper at the standby position has loaded. Choose Automatic to cut it when
the paper at the standby position during two days or more has loaded.
Specify the timing for automatic checks of nozzle clogging. Choose 1 page to check once per
printed page. Choose 10 pages to check once per ten printed pages. Choose Automatic to have
the printer automatically adjust the timing for checks based on the frequency of nozzle use.
Set the scan width of the carriage for printing. Select [Automatic] to move the carriage to meet
the width of the loaded paper. Selecting [Fixed] will reduce stains on the back of the paper but
at the cost of a somewhat longer print time.
Specify the period before the printer enters Sleep mode.
Choose the unit of measurement when roll length is displayed. You can switch the unit
displayed for Roll Length Set and the remaining paper amount displayed in the submenu.
Specify the time zone. Time zone options indicate a main city in this time zone and the
difference from Greenwich Mean Time.
Specify the date format.
Set the current date.
Set the current time.
Specify the language used on the Display Screen.
Adjust the Display Screen contrast level.
Restores settings that you have changed with Media Configuration Tool to the factory default
values.
Delete the file management information of the saved data in the HDD.
Overwrite the random data in the whole of the hard disk drive.
Overwrite 00 and FF and random data in the whole of the hard disk drive once at a time.
Execute the verify check whether the data has written correctly to the hard disk drive.
Choose how to print.
Select [Print] to perform normal printing. Select [Print (Auto delete)], print data and remove it
from the hard disk. Select [Save in mail box] to only save data to the box, without printing it.
Select [On] to start printing data when its save is complete.
Select [Off] to print data without saving it to the common box.
Indicates the job information that choose from the last three print jobs.
