Canon imagePROGRAF iPF825 Service Manual page 16

Chapter 1
[3]
[1] Ethernet Connector
[2] USB Port
[3] Manual Pocket
[4] Power Supply Connector
1-2
[2] [1]
[6]
[4]
[7]
[5]
F-1-2
T-1-2
[5] Lower Roll Unit Connector
[6] Carrying Handles
[7] Accessory Box
