2.3 VCOM Buffer
Figure 2-4 shows the buffer circuit for the ADC VCOM signal. The output of the VCOM buffer connects to the
VOCM signal of the input driver amplifiers. The J1 VCOM header pins (depopulated by default) can also be used
to provide an alternate source for VCOM by depopulating resistor R5. Jumper J1 can also be used to connect
the VCOM signal to an external piece of test equipment to set the common-mode voltage. A common use case
is to connect this signal to the Audio Precision SYS-2722 to set the signal generator's common-mode output.
AVDD
8
V+
C8
25V
0.1 µF
GND
2.4 ADC Connections and Decoupling
The circuit shown in Figure 2-5
connection has a 100nF decoupling capacitor and each power supply has a 10µF decoupling capacitor. These
capacitors are physically close to the device and have a good connection to the GND plane. Also, each digital
input has a 50Ω series resistor. These resistors smooth the edges of the digital signals so that the signals have
minimal overshoot and ringing. Although not strictly required, these components can be included in final designs
to improve digital signal integrity.
