Figure 20 Inline Filter - Removing The Filter - Metrohm 930 Compact IC Flex ChS Manual

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
1 Filter housing
Inline filter housing. Part of the accessories
(6.2821.120).
3 Filter (6.2821.130)
Pack contains 10 pieces.
930 Compact IC Flex ChS (2.930.1200)
Removing the filter
Figure 20 Inline filter – Removing the filter
1 Shutting off the flow
Switch off the high-pressure pump in the software.
2 Removing the inline filter
Unscrew both pressure screws from the inline filter.
3 Unscrewing the filter screw
Use two adjustable wrenches (6.2621.000) to loosen the filter screw
(20-2) from the filter housing (20-1) and unscrew it by hand.
4 Removing the filter
Remove the old filter (20-3) using tweezers.
2 Filter screw
Screw for the inline filter. Part of the acces-
sories (6.2821.120).
5 Operation and maintenance
￭￭￭￭￭￭￭￭
69
