Figure 4: Extracting the internal assembly
3.
Insert the tabs at the base of the pet mask into the bottom holes and align the tabs on the
sides with the holes on both sides. See the following figure.
Figure 5: Inserting the pet mask
4.
Press down gently to install the pet mask.
5.
Reassemble the internal assembly.
Note: Ensure that the microphone seal is in place. See the following image.
NEXT CAM PG+ Motion Detector with Integrated Camera Installation Guide
D-308840 NEXT CAM PG+ Rev. 0
5
