Configuring the device parameters

Enter the DEVICE SETTINGS menu and select the required configuration as described in the
following table.
Option Action
General configuration options
Alarm LED Define whether the alarm LED indication will be activated.
Optional settings: LED ON (default) and LED OFF.
Event counter Define whether an alarm will be activated upon continued motion (low
sensitivity) or upon a single alarm event (high sensitivity)..
Optional settings: LOW sensitivity (default) and HIGH sensitivity.
Disarm activity Define whether the device is active when the system is disarmed.
Optional settings: NOT Active (default), no delay, 5 s delay, 15 s delay, 30 s
delay, 1 min delay, 2 min delay, 5 min delay, 10 min delay, 20 min delay and
60 min delay.
AC monitoring Determine whether the device is connected to AC power. When enabled, the
device reports power failure and power restore events.
Optional settings: Disabled (default) and Enabled.
AC LED behavior Define whether the LED lights green when connected to AC power.
Optional settings: Always OFF (default) and Match AC.
Temperature Define the device temperature reporting mechanism.
reporting Optional settings: Disabled (default). For further configuration options, refer to
the control panel installation guide.
Camera configuration options
Image color Determine whether the image will be in black and white or color.
Optional settings: Black & White (default) and Color.
Alarm image Set the resolution of an image taken during an alarm.
Optional settings: VGA: 640 x 480, QVGA: 320 x 240 (default), QQVGA: 160 x 120
resolution
On-demand Set the resolution of an image taken for an on-demand image request.
image Optional settings: HD: 1280 x 720, VGA: 640 x 480, QVGA: 320 x 240 (default),
resolution QQVGA: 160 x 120
Image quality Set the quality of an image taken during an alarm.
Optional settings: Low (default), High.
Image Set the brightness of the image. Normal (default) is recommended for most
brightness conditions.
Optional settings: Normal (default), -3 (lowest), -2, -1, +1, +2, and +3 (highest).
Image contrast Set the contrast of the image. Normal (default) is recommended for most
conditions.
Optional settings: Normal (default), -3 lowest), -2, -1, +1, +2, and +3 (highest).
Microphone Determine whether to activate the microphone. When set to enable, the
settings microphone records sound only during image capturing.
Optional settings: Disable (default) and Enable.
