Installing the pet mask
Install the pet mask if you require pet immunity. The optimal installation height for pet immunity is
2.1 m (7 ft.), measured from the center of the device. Pet immunity is for pets weighing up to 38 kg
(85 lb).
Note: Pet immunity is not supported at heights of 2.4 m (8 ft.) and above. Do not install the pet
mask if you are mounting the device at this height or above.
Table 1: Required mounting height
Distance to opposite wall
8 m (26 ft) or less
8 m to 12 m (26 ft to 39 ft)
1.
To open the device cover, use a screwdriver to loosen the cover screw located on the
underside of the device. See A in the following figure. Separate the base from the cover. See B
in the following figure.
Figure 3: Device cover removal
2.
To extract the internal assembly, use a screwdriver to open the four clips. See A in the
following figure.
4
NEXT CAM PG+ Motion Detector with Integrated Camera Installation Guide
Mounting height
1.8 to 2.1 m (6 ft to 7 ft)
2.1 m (7 ft)
D-308840 NEXT CAM PG+ Rev. 0
