Control of the Switcher

You can choose to switch input sources at your convenience through front
panel buttons, IR remote or Hotkey function.

Front Panel Control

Users can choose to use front panel buttons to do basic switching
operations.
Connect the switcher as required and power on all the attached devices.
Press the corresponding button (Input1/2/3/4)
to select HDMI In (1/2/3/4) as input source

IR Remote Control

The included remote handset can be used to turn on and off a CEC-enabled
display device and to switch four HDMI sources to one display device.
Point the remote directly at the IR windows on front panel or at the IR
extension cable connected to the "IR Ext." on rear panel.
Turn on
a CEC-enabled display device
Select the previous source input
Select a specific source input
Button IR Codes
ON 0x1D
OFF 0x1F
0x1B
0x11
1 0x17
www.avaccess.com
Description
Turn on the connected CEC-enabled display.
Turn off the connected CEC-enabled display.
Switch to the previous source input (Cycle 4->1).
Switch to the next source input (Cycle 1->4).
Switch to source input 1.
5
Control of the Switcher
Turn off
a CEC-enabled display device
Select the next source input
