Rear Panel; Application - AV Access 4KSW41-KVM-Pro User Manual

Rear Panel

1 2
No. Name
1 DC 12V
2 IR Ext.
3 HDMI In (1~4)
4 HDMI Out
USB Host
5
(1~4)

Application

Warnings:
Before wiring, disconnect the power from all devices.

During wiring, connect and disconnect the cables gently.

(Such as PC or laptop) to HDMI IN 1~4 ports

Front Panel
Rear Panel
Connect HDMI
1
sources to HDMI
In 1-4 ports.
6 Connect to the power
adapter provided.
www.avaccess.com
3
Description
Connect to the power adapter provided.
Connect to the IR receive cable provided.
Connect to HDMI sources.
Connect to an HDMI display.
Connect to USB Host devices.
The USB Host 1~4 is bound with HDMI In 1~4
respectively. When an HDMI input is selected,
the corresponding host PC will be connected to
the USB devices connected to the switcher.
Connect USB keyboard to
4
USB 1.1 port and other USB
devices to USB 2.0 ports.
PC
PC
4
5
MIC
Removable
Keyboard Mouse
Hard Disk
5
Connect the
PCs to the USB
Host port (1~4).
PC PC
Application
4
Earphone
Connect a
3
Microphone
and an earphone
to MIC IN and
LINE OUT port
Connect an
HDMI display
2
device to HDMI
OUT port.
Display
