- Page 1 4KSW21-L VGA/HDMI Smart Switcher User Manual...
- Page 3 Technology Ltd. also makes no commitment to update or to keep current the information contained in this document. AV Access Technology Ltd. reserves the right to make improvements to this document and/or product at any time and without notice. Copyright...
-
Page 4: Important Safety Instructions
Important Safety Instructions Do not expose this apparatus to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the apparatus. Do not install or place this unit in a bookcase, built-in cabinet, or in ... -
Page 5: Table Of Contents
Overview Table of Contents Overview ........................2 Package Contents ........................3 Front Panel ........................... 4 Rear Panel ............................. 5 Installation Instructions ..................6 Specification ......................8 Warranty ........................ 11 www.avaccess.com... -
Page 6: Overview
Overview Overview 4KSW21-L is a VGA/HDMI Smart Switcher with direct CEC control, offering one HDCP compliant HDMI input, a VGA with analog stereo audio input, and an HDMI output up to 4K@60Hz (Chroma sub-sampling 4:2:0 8-bit only) without scaler. Its built-in CEC controller allows user to directly switch the power status of CEC-supported display device, such as TV or projector, eliminating the need of IR Remote. -
Page 7: Package Contents
Overview Package Contents Before you start the installation of the product, please check the package contents: 1 x VGA/HDMI Switcher 4KSW21-L 1 x Power Supply (DC 12V 0.5A) 1 x Mounting Brackets (Pair) 1 x User Manual ... -
Page 8: Front Panel
Overview Front Panel ID Name Description VGA IN Connects to VGA sources VGA analog stereo audio input HDMI IN Connects to HDMI sources VGA LED Lit when VGA source is selected Select Press this button to select VGA IN Button Select Press this button to select HDMI IN Button... -
Page 9: Rear Panel
Overview ID Name Description HDMI LED Lit when HDMI source is selected Power on/off the display devices via CEC. Select Note: The display device must support CEC and Buttons CEC must be enabled. Rear Panel Name Description Power DC 12V 0.5A power input Input Power LED Indicates power status... -
Page 10: Installation Instructions
Power on the HDMI display device to establish communication between equipment connected to the 4KSW21-L. Note: Enable the CEC function of the display device so that users can control the display device via CEC. To operate 4KSW21-L, use the front panel select button. www.avaccess.com... - Page 11 Installation Instructions Laptop Laptop Audio IN VGA IN HDMI IN HDMI OUT Display www.avaccess.com...
-
Page 12: Specification
Specification Specification Video Input 1 x HDMI , 1 x VGA Input Signal Type HDMI: HDMI1.4 with HDCP , VGA: VESA HDMI: 4096x2160@24/25/30/50/60Hz, 3840x2160@24/25/30/50/60Hz, 1080P, 1080I, 720P, 576p, 576i, 480p, 480i; VGA: Input Resolution Support 1920x1200/1920x1080/1680x1050/160 0x1200/1600x900/1400x1050/1440x90 0/1366x768/ 1280x1024/1280x800/1280x768/1280x 720/ 1024x768/800x600/640x480@60Hz Input Video Level 0.5~1.0 Vp-p... - Page 13 Specification Video HDMI: 4096x2160@24/25/30/50/60Hz, 3840x2160@24/25/30/50/60Hz, 1080P, 1080I, 720P, 576p, 576i, 480p, 480i; VGA: Output Resolution Support 1920x1200/1920x1080/1680x1050/160 0x1200/1600x900/1400x1050/1440x90 0/1366x768/ 1280x1024/1280x800/1280x768/1280x 720/ 1024x768/800x600/640x480@60Hz Audio Digital audio: Embedded in HDMI Input inputs Analog audio: Stereo Digital audio: Stereo, LPCM 5.1, LPCM 7.1; Dolby True HD, DTS-HD Master Input Signal Type Audio Analog audio: Stereo...
- Page 14 Specification General 0°C ~ 45°C (32°F ~ 113 °F), Operating Temperature/ 10% ~ 90%, non-condensing Humidity -20°C ~ 70°C (-4°F ~158 °F), Storage Temperature/ 10% ~ 90%, non-condensing Humidity Power Supply 12V 0.5A Product Weight 220g Power Consumption 1.5W Max Product Dimensions 141.8mm x 64.2mm x 20mm Human-body Model:...
-
Page 15: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide. - Page 16 AV Access Technology Limited V1.0.2...
