2x1 Triple Monitor DP KVM Switch Docking
iDock D23
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iDock D23 and is the answer not in the manual?

Questions and answers

Summary of Contents for AV Access iDock D23

  • Page 1 2x1 Triple Monitor DP KVM Switch Docking iDock D23 User Manual...
  • Page 2: Package Contents

    Package Contents Package Contents Before you start the installation of the product, please check the package contents: Switch Docking x 1  Power Adapter (DC 12V 3A) x 1  USB 3.0 Type-A to Type-B Cable x 2  DP 1.4a Cable x 6 ...
  • Page 3 Panel transmission. One CTL port, supports for connecting an extended button control  device (need to purchase separately) for button control. One SDXC card slot (maximum: 2TB) with the maximum  transmission rate of 104MB/s. One LAN port, support for 1Gb Ethernet performance. ...
  • Page 4 Application 1. LAN | 2. CTL | 3. DP OUT (A&B&C) | 4. USB HOST (1&2) | 5. DP IN (1A/1B/1C & DP IN 2A/2B/2C) | 6. Power In (DC 12V) | 7. USB-A (USB 3.0) Application Removable Headset Camera Monitor 1 Monitor 2 Monitor 3...
  • Page 5: Button Control

    Button Control into the two USB-B ports, which means that both computers can be connected to the network through USB-B cables, regardless of whether the computer is selected or not. The network should be connected to the LAN port. Button Control Users can choose to use front panel button or extended control button to do basic switching operations.
  • Page 6 Specifications Technical Expansion USB-A x5: • Three USB 3.0 ports, up to 5Gb/s, two of them share 2A current output, and one supports 1.5A current output; • One USB 2.0 port, up to 480Mb/s; • One USB 1.1 port, for keyboard connection. SDXC card: Up to 104MB/s, maximum support 2TB.
