One-Touch, Constant-Touch,
or Double-Tap
One-touch is the default setting of the control box and
requires only a single touch of a keypad button to move
the desktop to a saved height. Constant-touch requires
the continuous hold of a button or paddle to move the
desktop to a saved height. Double-tap requires pressing
the keypad button twice to move the desktop to a saved
height. This helps avoid accidental activation of the desk
if a keypad button is bumped.
Toggle between one-touch and constant-touch modes:
1. Hold the down button until the desk reaches its lowest
position.
2. Hold the down button again until the display flashes
"ASr."
3. Hold the "1" button until the display shows "10.1"
(one-touch), "10.2" (constant-touch), or "10.8" (double-
tap), and then goes back to "ASr." While the display is
flashing "ASr," hold the "1" button to toggle between
the three settings.
4. Wait for the display to change back to "ASr."
5. Hold the "down" button until the desktop lowers and
rises slightly and the display changes back to the
numeric height setting.
Calibrate Desk Height
Compare the desk height to the displayed height:
1. Press and hold the "down" button until the desk
reaches its lowest position.
2. Use a tape measure to check the height from the floor
to the top surface of the desktop. If the measurement
matches the displayed height, the desk is already
calibrated and ready for use.
If the displayed height doesn't match the desk's actual
height, follow these steps:
1. Hold the down button until the display flashes "ASr."
2. Hold the "M" button until the numeric display begins
flashing.
3. Tap the up or down button to adjust the displayed
height to match your desk's measured height.
4. Wait for the display to change back to "ASr."
5. Hold the "down" button until the desktop lowers and
rises slightly and the display changes back to the
numeric height setting.
18

Units of Measurement

Switch between inches and centimeters on your display:
1. Hold the down button until the desk reaches its lowest
position.
2. Hold the down button again until the display flashes
"ASr."
3. Hold the "2" button until the display shows "10.3"
(centimeters) or "10.4" (inches) and then goes back to
"ASr." While the display is flashing "ASr," hold the "2"
button to toggle between the two settings.
4. Wait for the display to change back to "ASr."
5. Hold the "down" button until the desktop lowers and
rises slightly and the display changes back to the
numeric height setting.
Max/Min Height Limits
Set the desk's maximum height limits:
1. Hold the up or down button to move the desk to the
desired height.
2. Tap the "M" button once and "S-" will appear on the
display.
3. Tap the up button and the display will flash "S-."
4. Hold the "M" button until the display shows "999" and
changes to the numeric height of the now set upper
limit.
Set the desk's minimum height limits:
1. Hold the up or down button to move the desk to the
desired height.
2. Tap the "M" button once and "S-" will appear on the
display.
3. Tap the down button and the display will flash "S-."
4. Hold the "M" button until the display shows "000" and
changes to the numeric value of the now set lower
limit.
Remove the maximum and minimum height limits:
1. Tap the "M" button once and the display will show "S-."
2. Hold the "M" button until the display shows "555" and
changes to the current numeric height setting.
