Uplift Desk V2-Commercial F600 C-Frame Manual page 15

Install Accessory Anchor Plates (optional)
Some UPLIFT Desk accessories are designed to attach to the
patented mounting points located on front and back of the
Crossbar Ends. Some of these accessories require the use
of the included Anchor Plates (P11). Refer to the instructions
provided with each accessory for specific mounting
instructions.
A. Align the two smaller holes in one of the Anchor Plates
with two of the threaded holes in the Crossbar End.
B. Loosely insert two of the M8 x 10 Machine Screws
through Anchor Plate holes and into the threaded holes in
the Crossbar End.
C. Tighten the screws using the 5mm Allen Wrench
Allen Wrench Handle (H15).
Flip Desk Over
When preparing to flip the desk over, be aware of any loose cables and attached accessories that could move during the
flipping process, like a Keyboard Tray or CPU Holder. Two people are recommended.
A. With one person located at each end of the desk, grasp the desk Leg with one hand and the desktop and Side Bracket
together with the other and carefully lift while rotating the desk so the Keypad is facing up.
B. Readjust your grip and continue to rotate the desk until it is rightside up.
(H7)
(H8)
© UPLIFT Desk • 800-349-3839 • info@upliftdesk.com •
and
Example locations for Anchor Plate attachment, refer to
accessory instructions for recommended mounting locations.
H7
upliftdesk.com
P11
