Uplift Desk 99.039.14.0050-V4 Programming Manual

PROGRAMMING YOUR UPLIFT DESK
These UPLIFT Desk programming instructions are compatible only with the Advanced 1-Touch
Digital Memory Keypad and control boxes with the following numbers located on the silver sticker:
HEIGHT CALIBRATION
Make sure the numeric display matches the actual height of the desktop in its lowest position.
1. Press the DOWN button until the desk reaches the lowest position.
2. Measure the height from the floor to the underside of the desktop. If the displayed height
does not match your measurement, follow the next steps.
3. Press the DOWN button until display flashes "RST".
4. Press the "M" button until the numeric display begins flashing.
5. Press the UP or DOWN button to set desk to the measured height.
6. Once display changes back to "RST", press the DOWN button until the desktop lowers slightly,
then rises slightly and the display changes back to the numeric height setting.
KEYPAD LOCK
The keypad can be locked to prevent accidental activation or movement of the desk.
To lock: Press and hold "M" button until display changes to "LOC"
To unlock: Press and hold "M" button until display changes to numeric height setting.
NOTE: If a power outage occurs, the program will automatically return to the unlocked setting.
MEMORY SETTINGS
Save up to four commonly used desk heights and recall them quickly.
l. Press the UP or DOWN button to move the desk to the desired height.
2. Press the "M" button.
3. Press the "1, 2, 3, or 4" button to assign the current height to a number on the keypad.
4. To recall any of those heights, press the numbered button to bring desk to assigned height.
CONSTANT-TOUCH & ONE-TOUCH
These steps allow the desktop to be set to either One-Touch or Constant-Touch. One-Touch requires
only a single touch of the "1, 2, 3, or 4" button to move the desktop to a preset memory location (One-
Touch is the default setting for 2-leg frames). Constant-Touch requires a continuous touch of the "1, 2,
3, or 4" button to move the desktop to a preset memory location (Constant-Touch is the default set-
ting for 3-leg and 4-leg frames).
Change between One-Touch and Constant-Touch:
l. Press the DOWN button until the desk reaches the lowest position.
2. Press the DOWN button again until display flashes "RST".
3. Press the "1" button until display shows "10.1" (One-Touch) or "10.2" (Constant-Touch)
and goes back to "RST".
Note: While "RST" is still flashing, you can press the "1" button as many times as you'd like
to toggle between the two settings.
4. Press the DOWN button until the desktop lowers slightly, then rises slightly and the display
changes back to the numeric height setting.
© UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com
Two-leg frame:
Three-leg frame:
Four-leg frame:
99.039.14.0050-V4
99.046.14.0070
99.052.09.0030
®
*Note: "RST" will look like
"ASr" on the display
R02
