INTECONT PLUS
Upper Display
Left
Right
Lower Display
Left
Right
TU
O Z1 = 50 000
Z2 = 60
Counter Z2
Counter Z3
Feed rate
Feed rate
Belt load
Belt load
Belt speed
Batching displays
1) related to nominal feed rate
2) related to nominal belt load
3) see "Batching Mode".
Display formats and units of counters Z1, Z2, Z3 and I
can be selected separately.
0837
Transmission to third parties and reproduction of
t h i s d o c u m e n ta t i o n a r e n o t p e r m i t t e d .
SchenckProcess GmbH reserves all rights of
ownership and copyrights.

Normal Displays

Rotating point as running message.
Scale has started, totalized amount
and feed rate are acquired.
In stop state of scale (point stands
still) only belt load and belt speed are
measured.
Totalizing counter Z1
Event message, alphanumerically
coded, e.g. E1 for power failure.
Selectable display
Select display
kg
0 kg/h
Z2 = 6000
Z3 = 1000
I = 1000
Ir = 50.00
Q = 10.000
Qr = 50.0%
V = 0.0500
Zb, ZI, Zd, Nb

Control In Normal Mode

g
Start totalization
Prerequisite : External release signal
Feature
B
Stop totalization
Feature
Belt load and belt speed continue
being measured.
i
Reset totalizing counters.
This function has to be activated with
parameters A10 or A11.
1
Enter number of desired counter
(1 or 2).
Counter no. : _
Counter 3 cannot be reset. In case of
overflow, counting resumes from 0.
f
Acknowledge input.
N
Correct faulty input or accidental use
of DELETE key.
TU
Select lower display
(see "Normal Display").
O
kg
Acknowledge event messages.
G
kg
kg/hr
Call further functions, e.g. display
% 1)
event messages, calibration.
N
kg/m
Exit function distributor.
2)
m/s
3)
Technische
Redaktion PDE-RD
VBW
available (selectable)
START source (B06)
set to OP or Keyboard
Mode active.
: Rotating point in left field
of upper display
: Point stands still
Control
BV-H2214 GB 5
