INTECONT PLUS
1. Event S 2 = O 0 7
N o R e l e a s e
Display shows
event name
event code
and a note
The note informs the operator of relevant parameter.
TU
N
List of Events
The events are listed in accordance with display
priority.
System messages
Electrics
Material flow
Calibration C
Maximum H
0837
Transmission to third parties and reproduction of
t h i s d o c u m e n ta t i o n a r e n o t p e r m i t t e d .
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
e.g. No Release
e.g. S2
e.g. Parameter O07.
Let you view various events.
Return to normal displays.
S1 Memory Error
S2 No Release*
S3 Scale Maintenance ON
S4 Maintenance Interval
Electrics
S7 Simulation active
S9 Host Communication
E1 Power Failure
E2 Namur Error Tacho*
E3 Namur Error Sensor*
E6 Error Ext. Event
B1 Out of Tolerance
B4 BATCH Actual Value MAX
C1 L/C Input *
C2 Tacho Input *
C3 Belt Skew
C4 Belt Drift
C5 Tare Correction > MAX
C7 ZERO Time
C8 Slip Error
C9 Tare Diff > MAX
H1 I > MAX
H2 Load > MAX
H3 v > MAX
H4 L/C Input > MAX
Minimum L
L1 I < MIN
L2
L3 v < MIN
L4 L/C Input < MIN
I
=
Feed Rate
V
=
Belt Speed
L/C
=
Load Cell
* Fault on device or cabling
Contact Outputs
General Alarm
available until acknowledged
MIN/MAX Outputs independent of event class,
active also in IGNORE class.
Limit values are reported as long
as event is available and only
with active scale.
Technische
Redaktion PDE-RD
VBW
Load < MIN
Control
BV-H2214 GB
7
