Control Overview

{
READY POWER ON
CPU OK
ALARM
MIN
MAX
gB
U
SCROLL
T
i
RESET
G
FUNCTION
O
DELETE
N
ESCAPE
f
ENTER
P
DATA
0837
Transmission to third parties and reproduction of
t h i s d o c u m e n ta t i o n a r e n o t p e r m i t t e d .
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
RUNNING MESSSAGE, OPERATING STATUS
EVENT MESSAGES
Z1 = FEED AMOUNT
I = FEED RATE
ACKNOWLEDGE
o Z1 = 1500 kg
-- I = 100 kg/h
STOP
START
RESET
COUNTER
FUNCTION DISTRIBUTOR
Start/Stop
Select lower display line and functions.
(1) Counters Z2, Z3
(2) Feed rate I
(3) Feed rate Ir in %
Reset counter(s)
(1) Enter number of desired counter (1 or 2).
(2) Use ENT key
(3) Use ESCAPE key
(4) Use DELETE key
Call function distributor and event messages
(1) SCROLL keys let you select desired function.
If an event is available, "Display Event" function is preselected.
(2) ENTER key lets you activate function.
(3) SCROLL keys let you view available event messages one after the other.
(4) ESCAPE key lets you return to normal displays.
Acknowledge event messages, delete inputs.
Abort function and return to normal displays.
Acknowledge input, e.g. setpoint,
start functions, e.g. Display Events (see "FUNCTION").
Prepare input, e.g. parameters.
ABORT
FUNCTION
START
PREPARE
FUNCTION
ENTRY
PRESELECT LOWER
DISPLAY
if preselected
(4) Belt load Q
(5) Belt speed v
to acknowledge.
to abort input.
to delete faulty digits.
Technische
Redaktion PDE-RD
VBW
H2
kg/m
L2
m/s
H3
C1
L3
L4
M
S2
EVENT MESSAGES
Control Overview
BV-H2214 GB
