INTECONT PLUS
L 01 Protocol Type
Range: NO
MODBUS COMP.
S5-BCC COMP.
MODBUS
PROFIBUS DP
DEVICENET
MODBUS/TCP
Every protocol requires an optional interface card to
be present.
"COMP" identifies the compatible protocols.
Protocol Type MODBUS/
MB-COMP
.
VEG VSS
BLOCK L
L 01 Protocol Type
L 02 TIMEOUT Host
L 03 Comm. Error Host
L 04 Word sequence
L 05 Byte sequence
L 06 Configuration
L 07 Address
L 08 Resolution
L 09 Physical attributes
L 10 Baud Rate
L 11 Data format
L 12 Adresse
L 13 FLOAT-FORMAT
L 14 Address
L 15 Baud Rate
L 16 S5-Physical attributes
L 22 Hardware
Tabelle der aktiven Parameter abhängig vom Protokolltyp
L 02 TIMEOUT Host
Range: 1...600s
If timeout value exceeds zero, a message from host
system is expected to arrive during set time.
0837
Transmission to third parties and reproduction of
t h i s d o c u m e n ta t i o n a r e n o t p e r m i t t e d .
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
Block L :
Default: NO
S5-BCC Comp. MODBUS
VSS VSS
Default MODBUS/
MB-COMP.
NO x
5 s x
IG (S 09) x
I:std/L:std x
High - Low
FIXED
1 x
4096 x
RS 485 x
9600 x
8-E-1 x
16
IEEE
63
125K
RS422
VxB020
.
Default: 10s
Communication Fieldbus
PROFIBUS DP DeviceNet
VPB 020/8020 VCB
020/8020
PROFIBUS DEVICENET MODBUS/
DP TCP
x x x
x x x
x x x
x x
x
x x
x
x
x
x
x x
L 03 Comm. Error Host
Range: IGNORE
W1 (Warnung 1)
W2 (Warnung 2)
A (Alarm)
If no message is received during the time set by
Parameter L02, event message S9 "Data Link Host" is
output.
Technische
Redaktion PDE-RD
VBW
MODBUS TCP ETHERNET IP
VET 020 VET 022
ETHERNET/ S5-BCC Comp.
IP
x x
x x
x x
x
x
x
x
x
x
x
Default: ALARM
Parameterization
BV-H2214 GB
S9
