VBW
Start and Abort
g
Start batch, process starts.
Display ZI moves from 0 towards
setpoint
Display Zd moves from setpoint
towards 0.
B
Abort batch.
Batching continues upon next start
command.
Deselect Batch
Lets you deselect batching mode, i.e. mode is removed
from active functions available.
Totals sign disappears from upper display, batching
values ZI, Zd, Zb and Nb are no longer available, but
remain stored.
Prerequisites : Batch complete, or aborted using
"Abort Batch" function; scale OFF.
GT
Call function distributor,
select "Deselect Batch" function,
f
and acknowledge.
Use "Select Batch" function to reactivate batching
mode.
Old values ZI, Zd, Zb and Nb can be viewed again.
Abort Batch
This function lets you abort a running batch, i.e.
batching immediately stops.
Batching mode remains selected.
New batch starts upon next start command, old batch
is not resumed.
Use "Make-up" function to complete old batch.
GT
Call function distributor and select
"Abort Batch" function.
f
Acknowledge.
You can also abort batch using the P02 contact.
Control
BV-H2214 GB 10
Make-up
Lets you add a selected amount of material to a batch
aborted or complete.
Prerequisites :
Display ZI
Display Zd
Display Zbn
Display Zdn
You can scroll all displays into lower display field
using cursor keys.
Zdn and Zbn are available only until start of next
batch.
GT
f
P
gB
If make-up batch is complete, normal batch starts
upon next start command.
For new make-up, call function again.
"Abort Batch" function also aborts make-up
operations.
Technische
Redaktion PDE-RD
INTECONT PLUS
Running batch complete, scale OFF.
No batch printout.
: Batch actual setpoint resumes from
achieved value.
: Batch residual value remains
unchanged.
: Make-up setpoint
: Batch residual value of make-up
amount
Zdn = Zbn - make-up amount
already fed.
Call function distributor and select
"Make-up" function.
Acknowledge.
System prompts for input of
make-up setpoint Zbn in kg or t.
The units is that of Counter 1.
Until start of make-up, setpoint Zbn
can be changed.
Start or abort make-up
