INTECONT PLUS
Program running:
>. C W :
Set / Act
Upper display : residual run time in % of total run time
Lower display : continuously
Program complete:
>. CW: 1200,34 kg
COR 0,99915
Upper display : Fictitious material amount fed over
Lower display : mean value KOR of SET/ACT over
fN
Special Messages:
(1) START
(2) ABORTED
* Lets you check scale zero point without check
weight.
Display format: xxxxxxx,yy kg
0837
Transmission to third parties and reproduction of
t h i s d o c u m e n ta t i o n a r e n o t p e r m i t t e d .
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
5 1 , 4 %
0 , 9 8 4 2
meaned
measuring result
run time *.
total run time
Exit program.
Since result is not
AUTOMATICALLY ACQUIRED,
both keys are equivalent.
if belt is not running
(irrelevant)
Evaluating Result:
Error < 1 %
Error < 5 %
SET/ACT Error > 5 %
Check does not consider Parameter D 02 "Range
Correction", so that check program will indicate
same error quotient KOR after check.
Technische
Redaktion PDE-RD
: KOR = 0.99...1.01
Scale OK, no further action required.
: KOR = 0.95...1.05
Enter KOR value into Parameter D
02.
This make good sense only if
parameter has not yet considered
result of check using material.
: KOR < 0.95, or KOR > 1.05
Multi-percent deviations
faulty data input (e.g. belt incination,
lever arms not exactly known), and/or
mechanical faults
distorsions).
Setting Programs
BV-H2214 GB
VBW
suggest
(misalignment,
