INTECONT PLUS
N 01 CPD Active
Range: NO
YES
Starts speed-controlled delay element used to shift
belt load measurement to the point of material
discharge.
Prerequisites:
N 02 Platf.Dis.Length
Range: 0.00...50.00 %LB
Input required only with CPD active
Length from mid platform to material discharge point
in % of total belt length LB.
The resolution is approx. 200.
N 03 Belt Sensor Active
Range: NO
YES
Belt sensor and sensor area on conveyor belt are
designed to acquire belt slip and belt drift, and
synchronize the adaptive belt influence compensation
BIC.
0837
Transmission to third parties and reproduction of
t h i s d o c u m e n ta t i o n a r e n o t p e r m i t t e d .
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
Block N :
Default: NO
Speed meter must be present and
active. No belt circuit sensor is
required.
Default: 0.00 %LB
Default: NO
Scale Monitoring
N 04 Source Sensor
Range: —
DI
Digital input for belt sensor. Can be checked using the
relevant service value.
Only DI6 can be used. If you select alternative "-", BIC
and belt monitoring functions cannot be used.
N 05 BIC Active
Range: NO
YES
Lets you start adaptive belt influence compensation
BIC.
To initialize BIC:
The dynamical tare portion is cleared upon power-up
or after changes to a parameter of the following list:
·
Parameter N 05 "BIC Active"
·
Parameter B 04 "vs Charact. Val."
·
Parameter D 06 "Belt Circuit Char"
Brief instructions:
1. N03 = YES, enter N 06... N 08.
2. Start setting program "LB: IMP/Belt".
3. Activate BIC (N05 = YES).
4. Tare.
Technische
Redaktion PDE-RD
VBW
Default: DI (DI6)
Default: NO
Parameterization
BV-H2214 GB 71
