VBW

Activate/Deactivate EasyServe

This function lets you control your INTECONT using
the "EasyServe" PC service tool.
GT
Call function distributor and select
"Activate EasyServe" function.
Enter communication parameters using Block R.
Condition:
This function has to be activated
with the parameter A09.
Note:
Upon power failure, the current
status is stored, i.e. the "Activate
EasyServe" function needs not be
reselected.
Connection to PC can also be made using a 9-pole
SUB-D connector on X4 (RS 232 only) or a Phoenix
connector on X5 (RS232, RS422 or RS485).
See also Wiring Diagram in chapter DETAILS.

Prefeeder

The "Start/Stop Prefeeder" function lets you activate or
deactivate prefeeder. Select "Start", and INTECONT
will control your prefeeder. In Stop state, material flow
is interrupted and scale can be tared.
Prerequisites :
External prefeeder present and
controlled by INTECONT.
Activate function using parameter
N 01.
GT
Call function distributor and select
"Start Prefeeder" or "Stop Prefeeder"
function.
f
Start control signal.
Control
BV-H2214 GB
12
The printing functions are available only if the option
card is present.
Print Batch
The batch report can be printed:
1. using "Print Batch" function
2. automatically after each complete batch
Start of printing disables the "Make-up" function for the
current batch.
Prerequisites :
Print format
GT
N
Batch Number:
20.11.02:
Batch Setpoint:
Batch Actual Val.: Amount batched (actual value)
Totalizer 2:
Zero Set before: Feeder run time after last taring or
Events
Technische
Redaktion PDE-RD
INTECONT PLUS

Printing

(Parameter J02 = YES).
Batch complete, scale OFF.
:
Order of sequence, line and column
divisions can be selected at will
(Parameter Block J).
Call function distributor and select
"Print Batch" function.
Start function.
Abort printing.
Batch Nummer 40
20.11.02
Batch Setpoint
Batch Actual Val.
Totalizer 1
Totalizer 2
Zero Set beforer
Events
E1
Power Failure O01
Consecutive number of batch
Date and time
Preset batch amount
Totalizer 1:
Totalizing counter 1
Totalizing counter 2
zeroing operation (see Service
Values)
:
available during printing
16:49:41
0.150 t
0.150 t
0.806t
806.47 kg
19 min.
Transmission to third parties and reproduction of
this documentation are not permitted. Schenck
Process GmbH reserves all rights of ownership
and copyrights.
0837
