INTECONT PLUS
MAX
=
Relay output for limit value monitoring
Open = MAX value exceeded up
Feed rate, belt load, or belt speed, can be
monitoring separately for excess of MIN
and MAX values.
FAULT
=
Relay output for alarms
Open = Alarm
FULL
=
Relay output for full feed in batching
mode
Closed = full feed
DRIBBLE =
Relay output for dribble feed
Closed = dribble feed
MOTOR =
Control output for belt drive
Closed = ON
PREF.
=
Control output for prefeeder
Closed = On
RELEASE
Release signal for totalization
=
H = Release
ON/OFF =
Start scale and totalization.
High = ON
OFF
=
Stop
Low = STOP
COUNTER= Pulse output for connection of external
totalizing counter
For simple measuring tasks, with constant belt speed,
speed transducer D can be omitted.
0837
Transmission to third parties and reproduction of
t h i s d o c u m e n ta t i o n a r e n o t p e r m i t t e d .
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
Technische
Redaktion PDE-RD
VBW
Overview
BV-H2214 GB
3
